vendor:generalplus
Die vendor Die ID Product Product description Notes
GFI449
AU-1

SO8C3CR35823
GPLB52A24A-048A?
GPLB52A24A-049A?
1000/2000 Dots Mono/4-Gray-Level LCD Controller/Driver with 8-CH sound processing unit (SPU) eBay lot

Have AU-1, AU-4
Not sure original box at this point
GFI449
AU-2

SO8C3CR35823
GPLB52A24A-048A?
GPLB52A24A-049A?
1000/2000 Dots Mono/4-Gray-Level LCD Controller/Driver with 8-CH sound processing unit (SPU)
gplb52a24a-048a.jpg GFI449
AU-3

SO8C3CR35823
GPLB52A24A-048A?
GPLB52A24A-049A?
1000/2000 Dots Mono/4-Gray-Level LCD Controller/Driver with 8-CH sound processing unit (SPU)
GFI449
AU-4

SO8C3CR35823
GPLB52A24A-048A?
GPLB52A24A-049A?
1000/2000 Dots Mono/4-Gray-Level LCD Controller/Driver with 8-CH sound processing unit (SPU)
2053 Chinese calculator
GHG554 GPY0030x “Hasbro GHG554”
Mike furby 2012
gpl168001a-068a-c.jpg Sunplus PU7967A-P69 GPL168001A-068A-C
GCH 462 Tamagotchi 2017
GFI435-NU4 TamaTown
gpl162002a-003a-c.jpg GCM
293
GPL162002A-003A-C

Generally not a lot of info on these. However, their datasheets show the (rough?) pad layout, which can be used to help identify them. Used in LCD toys / products.

https://fccid.io/PQ337480DDTG14/Schematics/Circuit-Diagram-2483636.iframe

  • 37480DDTG14 TAMAGOTCHI FRIENDS DIGITAL FRIEND Schematics Schematic Prints Bandai (HK) Company Limited
  • U2: GPLb52001a

Some stuff on eBay:

  • GPLB52A24A dies
  • NEW Generalplus GPL162006A-E-32 32-CH SoC System on a Chip EMU Board/Module/Card
  • Generalplus Universal Keypad Board/Module/Card Assembly GPC-1273
  • Generalplus GPCE063 V1.1 Comair Demo Board/Module/Card Assembly GPC-1333B
  • Generalplus GPT100A Touch Key/Pad Board/Module/Card Assembly GPC-1248G
  • Generalplus GPL32 V2.2 SoC System on a Chip EMU Board/Module/Card Assembly
  • NEW Generalplus GPL32650A-303-EV-C Board/Module/Card Assembly GPL32650A-303A
